NMC Cylindrical Batteries - Fueling the U.S. battery supply chain and manufacturing through high-quality industrial materials

Model	Nominal Voltage (V)	Typical Capacity (mAh)	Internal Impedance (mΩ)	Dimension (Diameter × Height mm)	Charge Rate	Discharge Rate	Weight (g)
10440	3.7	280	≤80	10.2±0.3 × 43.0	0.5C	0.5C	8.0
10440	3.7	320	≤80	10.2±0.3 × 43.0	0.5C	0.5C	9.0
10440	3.7	350	≤80	10.2±0.3 × 43.0	0.5C	0.5C	9.0
10500	3.7	400	≤80	10.2±0.3 × 50.0	0.5C	0.5C	10.0
10500	3.7	420	≤80	10.2±0.3 × 50.0	0.5C	0.5C	10.0
13430	3.7	650	≤80	13.2±0.3 × 43.0	0.5C	0.5C	13.5
13430	3.7	750	≤80	13.2±0.3 × 43.0	0.5C	0.5C	15.0
14250	3.7	200	≤80	14.2±0.3 × 25.0	0.5C	0.5C	8.0
14330	3.7	500	≤80	14.2±0.3 × 33.0	0.5C	0.5C	13.0
14330	3.7	600	≤80	14.2±0.3 × 33.0	0.5C	0.5C	14.0
14430	3.7	650	≤60	14.2±0.3 × 43.0	0.5C	0.5C	15.0
14430	3.7	700	≤60	14.2±0.3 × 43.0	0.5C	0.5C	15.3
14500	3.7	700	≤60	14.2±0.3 × 50.0	0.5C	0.5C	17.0
14500	3.7	800	≤60	14.2±0.3 × 50.0	0.5C	0.5C	18.0
14500	3.7	1000	≤60	14.2±0.3 × 50.0	0.5C	0.5C	19.0
14500	3.7	1200	≤60	14.2±0.3 × 50.0	0.5C	0.5C	20.0
14650	3.7	2000	≤60	14.2±0.3 × 65.0	0.5C	0.5C	23.0
16340	3.7	600	≤60	16.2±0.3 × 34.0	0.5C	0.5C	15.0
16340	3.7	700	≤60	16.2±0.3 × 34.0	0.5C	0.5C	17.0
16500	3.7	1200	≤60	16.2±0.3 × 50.0	0.5C	0.5C	22.0
16650	3.7	1200	≤60	16.2±0.3 × 65.0	0.5C	0.5C	23.0
18350	3.7	700	≤60	18.2±0.3 × 35.0	0.5C	0.5C	17.5
18350	3.7	800	≤60	18.2±0.3 × 35.0	0.5C	0.5C	18.5
18350	3.7	900	≤60	18.2±0.3 × 35.0	0.5C	0.5C	19.5
18500	3.7	1000	≤60	18.2±0.3 × 50.0	0.5C	0.5C	21.0
18500	3.7	1200	≤60	18.2±0.3 × 50.0	0.5C	0.5C	23.5
18500	3.7	1400	≤60	18.2±0.3 × 50.0	0.5C	0.5C	27.5
18500	3.7	1500	≤45	18.2±0.3 × 50.0	0.5C	0.5C	29.5
18500	3.7	2000	≤45	18.2±0.3 × 50.0	0.5C	0.5C	32.5
18650	3.7	1200	≤60	18.2±0.3 × 65.3	0.5C	0.5C	36.0
18650	3.7	1500	≤60	18.2±0.3 × 65.3	0.5C	0.5C	38.0
18650	3.7	2000	≤60	18.2±0.3 × 65.3	0.5C	0.5C	41.0
18650	3.7	2200	≤60	18.2±0.3 × 65.3	0.5C	0.5C	42.0
18650	3.7	2400	≤60	18.2±0.3 × 65.3	0.5C	0.5C	44.0
18650	3.7	2600	≤60	18.2±0.3 × 65.3	0.5C	0.5C	45.0
18650	3.7	2800	≤45	18.2±0.3 × 65.3	0.5C	0.5C	46.0
18650	3.7	3000	≤45	18.2±0.3 × 65.3	0.5C	0.5C	48.0
18650	3.7	3200	≤45	18.2±0.3 × 65.3	0.5C	0.5C	50.0
18650	3.7	3400	≤40	18.2±0.3 × 65.3	0.5C	0.5C	51.0
18650	3.7	3500	≤40	18.2±0.3 × 65.3	0.5C	0.5C	52.0
21700	3.7	3000	≤40	21.2±0.3 × 70.0	0.5C	0.5C	63.0
21700	3.7	4000	≤40	21.2±0.3 × 70.0	0.5C	0.5C	65.0
21700	3.7	4600	≤40	21.2±0.3 × 70.0	0.5C	0.5C	65.0
21700	3.7	5000	≤40	21.2±0.3 × 70.0	0.5C	0.5C	67.0
22650	3.7	4000	≤40	22.2±0.3 × 65.3	0.5C	0.5C	65.3
26700	3.7	3000	≤40	26.2±0.3 × 70.0	0.5C	0.5C	85.4
26700	3.7	3500	≤40	26.2±0.3 × 70.0	0.5C	0.5C	86.5
26700	3.7	4500	≤40	26.2±0.3 × 70.0	0.5C	0.5C	87.5
26700	3.7	5000	≤40	26.2±0.3 × 70.0	0.5C	0.5C	89.5
26700	3.7	5700	≤40	26.2±0.3 × 70.0	0.5C	0.5C	89.5
