Model: XE-DH650
XE-DH650 is the most popular AC pulse Spot Welder driven by compressed air, which is controlled by microcomputer. It is designed for the production of the world’s high-class battery manufacturer (NiMH. NiCd, Li-Ion/LiMnNi. LifePO4) with reliable performance. It is used for the welding of the negative electrode shell and the tab of the cylindrical battery (single-needle welding).
Features：
*The welding current is stable, the solder joint size is uniform, the solder joint is beautiful, the spark is small, and there is no blackening.
* Completely overcome the low pressure and water out of the lithium battery after spot welding, is the ideal equipment for the production of assembled batteries.
* Single-pulse, double-pulse and multi-pulse welding can be realized by microcomputer single-chip control.
* All parameters are digital settings, so the parameter adjustment is intuitive and accurate.
*The welding pin pressure is independently adjusted, and the adjustment is convenient, ensuring stable and reliable welding pressure.
* Alignment welding is accurate, suitable for welding of small cap batteries, and the yield is high.
* The appearance is exquisite and beautiful, and light.
Specifications
| Working Voltage | 110 VAC, 50/60Hz or 220VAC, 50/60Hz |
| Output Power | 10KW |
| Input Air Pressure | 0.1 – 0.7 MPa (Air Compressor is not included) |
| Welding Current | 0-99% Adjustable |
| Tab Thickness Applicable | 0.03 – 0.25 mm tab
Note: the spot welder is not suitable for welding foil ( <20-micron thickness with tab. For the thin foil welding, please consider the ultrasonic welder |
| Product Dimensions | L400×W560×H400mm |
| Warranty | One year limited warranty with lifetime support
Rusting and damage due to improper storage condition or maintenance is not covered by warranty |
| Accessories | pedal type welding switch
Air Compressor connect cable |
| Net Weight | 45kg |
