High-Purity Nickel Foil, Sheet and Plate (99.99%)
SKU: XN-NIF-HP
High-Purity Nickel Foil, Sheet and Plate (99.99%) is available as nickel foil, sheet and plate for battery-electrode, electrochemical and materials research. Documented thickness ranges extend from 0.01 mm foil to 10 mm plate, with custom dimensions and processing available.
Request a competitive quote and specify the required form, thickness, width, length and surface finish.
High-Purity Nickel Foil, Sheet and Plate (99.99%)
Product Type: High-Purity Nickel Foil, Sheet and Plate
Product Code: XN-NIF-HP
Brand: Xnergy
Product Introduction
This high-purity nickel material is supplied in foil, sheet and plate forms for electrochemical testing, battery research and functional-material development. The supplied references identify 99.99% purity and multiple thickness ranges for laboratory and industrial research requirements.
Core Features
- High-purity 99.99% nickel material
- Foil, sheet and plate formats covering 0.01–10 mm thickness
- Good documented electrical conductivity and electrochemical stability
- Good ductility for cold working, laser cutting and bending
- Documented oxidation and corrosion resistance in many acidic, alkaline and high-temperature environments
- Ferromagnetic nickel material for magnetic-field-related research
- Custom dimensions, cutting, punching and forming available
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Code | XN-NIF-HP |
| Brand | Xnergy |
| Material | High-purity nickel (Ni) |
| Purity | 99.99% |
| Product Forms | Nickel foil, sheet and plate |
| Nickel Foil Thickness | 0.01–0.1 mm |
| Nickel Sheet Thickness | 0.1–2 mm |
| Nickel Plate Thickness | 2–10 mm |
| Standard Widths | 5 cm, 10 cm, 20 cm and 30 cm |
| Standard Lengths | 10 cm, 50 cm, 1 m, 2 m and 10 m |
| Surface Options | Polished, matte, roughened or electroplated |
| Optional Plated Layers | Gold, platinum or IrOx |
| Customization | Custom sizing, cutting, punching and forming |
Applications
- Fuel-cell and alkaline-water-electrolysis electrodes
- Lithium-battery and solid-state-battery current collectors and electrode substrates
- Electrocatalysis, material analysis and electrochemical performance testing
- Thin-film deposition, surface treatment and interface analysis
- Electrodes combined with Pt, IrOx, NiFeOx or CoFeOx coatings for HER, OER, ORR and CO₂-reduction studies
- Conductive components, magnetic components and corrosion-resistant research parts
Note: Confirm the required foil, sheet or plate form, thickness, dimensions and surface treatment when requesting a quotation. Browse the Specialty Metal Foils & Sheets category for related metal foils and sheets.
