Lithium-Aluminum Alloy Strip

Lithium-Aluminum Alloy Strip

SKU: XN-LiAl-STRIP

Lithium-Aluminum Alloy Strip & Foil (XN-LiAl-STRIP) — Al content 0.1–5.0 wt%; standard strip: T 0.1–50 mm × W 4–300 mm; ultra-thin foil: T 20–100 μm × W 50–350 mm; custom range: T 0.02–50 mm × W 4–400 mm; used as anode in lithium primary and lithium alloy secondary batteries.

Need a bulk order? Request a competitive quote today!

Name: Lithium-Aluminum Alloy Strip & Foil

Material Type: Lithium-Aluminum Alloy Foil/Strip — Multiple Dimensional Ranges

Product Code: XN-LiAl-STRIP

Product Introduction:

Lithium-aluminum alloy strips and foils in multiple dimensional ranges. Mainly used for lithium primary battery anodes and lithium alloy secondary battery anodes. Appearance: flat and glossy surface, free from oil stains or other visible foreign matter; no visible oxidation or nitride formation; free from pores, cracks, or folds; slight processing lines allowed.

Key Features:

Al content: 0.1–5.0 wt%, remainder lithium (other ratios customizable)
Standard strip: thickness 0.1–50 mm × width 4–300 mm
Extra-wide strip: thickness 0.1–4 mm × width >300–400 mm
Ultra-narrow foil: thickness 0.05–4 mm × width <10 mm
Ultra-thin foil: thickness 20–100 μm × width 50–350 mm
Custom range: thickness 0.02–50 mm × width 4–400 mm
Application: lithium primary battery anodes and lithium alloy secondary battery anodes
Alloy development: Li-Al, Li-Zn, Li-Y, Li-Zr, Li-Cd, Li-Pb, Li-Si, Li-Ag; binary/ternary/quaternary

Chemical Specifications:

Aluminum content: 0.1–5.0 wt%, remainder lithium. Other alloy compositions customizable upon request.

Standard Lithium-Aluminum Alloy Strip Dimensional Tolerance:

Thickness (mm) Thickness Tolerance (mm) Width (mm) Width Tolerance (mm)
0.1–0.3 ±0.01 4.0–30 ±0.1
>0.3–0.6 ±0.015 >30–75 ±0.2
>0.6–0.8 ±0.02 >75–300 ±0.3
>0.8–1.0 ±0.03 — —
>1.0–4.0 ±0.04 — —
>4.0–10.0 ±0.1 — —
>10.0–50.0 ±0.3 — —

Extra-Wide Lithium-Aluminum Alloy Strip Dimensional Tolerance:

Thickness (mm) Thickness Tolerance (mm) Width (mm) Width Tolerance (mm)
0.1–0.3 ±0.01 >300–400 ±0.2
>0.3–0.6 ±0.02 >300–400 ±0.2
>0.6–0.8 ±0.03 >300–400 ±0.2
>0.8–1.0 ±0.04 >300–400 ±0.2
>1.0–4.0 ±0.05 >300–400 ±0.2

Ultra-Narrow Lithium-Aluminum Alloy Foil Dimensional Tolerance:

Thickness (mm) Thickness Tolerance (mm) Width (mm) Width Tolerance (mm)
0.05–0.1 ±0.005 <10 ±0.1
>0.1–0.3 ±0.01 <10 ±0.1
>0.3–0.6 ±0.02 <10 ±0.1
>0.6–0.8 ±0.03 <10 ±0.1
>0.8–1.0 ±0.04 <10 ±0.1
>1.0–4.0 ±0.1 <10 ±0.1

Ultra-Thin Lithium-Aluminum Alloy Foil Dimensional Tolerance:

Thickness (μm) Tolerance (μm) Width (mm)
20–100 ±5 50–350

Note: Specifications are for reference only. Dimensions and alloy compositions are customizable upon request. For pure lithium metal products, see Metallic Lithium Series.
