Planetary Centrifugal Vacuum Mixer XN-PVMC-300mL
SKU: XN-PVMC-300mL
Planetary Centrifugal Vacuum Mixer XN-PVMC-300mL is a benchtop bladeless mixing and defoaming system that uses planetary rotation and revolution under vacuum to homogenize and degas slurries, powders, and high-viscosity materials. Without contact between mixing blades and material, contamination is minimized.
The unit features dual 300 mL containers (10 / 30 / 50 / 100 / 150 mL optional), revolution speed up to 2000 rpm with infinitely variable adjustment, vacuum down to −98 kPa, PLC dual-loop control with touchscreen interface, six parameter memory groups, three-segment programmable timing, and dual counterweight balancing for safe high-speed operation.
Need a bulk order or custom specification? Request a competitive quote today!
Name: Planetary Centrifugal Vacuum Mixer XN-PVMC-300mL
Equipment Type: Bladeless Planetary Centrifugal Vacuum Mixer / Defoamer
Product Code: XN-PVMC-300mL
Brand: Xnergy
Product Introduction:
Planetary Centrifugal Vacuum Mixer XN-PVMC-300mL is a benchtop bladeless mixing and defoaming system that combines planetary rotation, revolution, and vacuum in a single sealed chamber. Centrifugal force from container rotation, combined with convection induced by revolution, homogenizes the material — while vacuum down to −98 kPa effectively removes sub-micron bubbles. Because no mixing blade contacts the material, contamination is minimized. The unit is designed for mixing and degassing battery slurries and powders, carbon nanotubes, nano-powders, conductive ceramics, oxide powders, and metal powders, and is supplied with dual 300 mL containers as standard.
Key Features:
Bladeless planetary-centrifugal mixing — no contact between mixing element and material, minimizing contamination
Dual-container, dual-center mixing and defoaming layout for larger working volume
Strong cooling airflow with rapid heat dissipation, low noise, and high-speed operation
High precision, low friction, durable, and ultra-quiet drive
Smart viewing window for clear observation of the mixing chamber
Vacuum pressure removes sub-micron bubbles from material
Touchscreen HMI for convenient and safe operation
Suitable for liquid and powder materials including battery slurries, carbon nanotubes, nano-powders, conductive ceramics, and oxide/metal powders
Technical Specifications:
| Parameter | Specification |
|---|---|
| Power Supply | Configurable according to local electrical standards |
| Total Power | 1.35 kW (drive motor 750 W) |
| Working Principle | Planetary gravity-driven mixing/defoaming (rotation : revolution = 0.66 : 1, fixed) |
| Revolution Speed | 300 – 2000 rpm (infinitely variable, 1 rpm precision) |
| Rotation Speed | 0.66 × revolution speed |
| Rotation Linear Speed | 5.41 m/s |
| Standard Container | 300 mL × 2 (Φ77 × H85 mm) |
| Optional Container Sizes | 10 / 30 / 50 / 100 / 150 mL |
| Maximum Capacity | 300 g × 2 |
| Maximum Viscosity | 300,000 cps |
| Vacuum Flow Rate | 165 L/min |
| Vacuum Pressure | −98 kPa (0.1 kPa precision, adjustable with vacuum delay) |
| Parameter Memory | 6 groups |
| Balancing | Dual-side counterweight adjustment |
| Timing | 0 – 600 s, 3 segments (1 s precision, max 200 s/segment) |
| Control System | Dual-loop PLC, Chinese touchscreen HMI |
| Lubrication | Cup-sleeve splash-proof structure, passive lubrication |
| Transmission | Gear drive |
| Dimensions (W × D × H) | 400 × 580 × 590 mm (excluding projections) |
| Weight | 80 kg |
Safety & Alarm Functions:
Imbalance alarm
Top-lid-not-closed alarm
Overload alarm
Automatic stop on fault
Automatic lid-locking during operation
Application Areas:
XN-PVMC-300mL is suitable for:
Lithium-ion battery slurry and powder mixing and defoaming
Carbon nanotube and nano-powder dispersion
Conductive ceramic, oxide, and metal powder mixing
High-viscosity material homogenization (up to 300,000 cps)
R&D workflows requiring contamination-free, bubble-free sample preparation
Maintenance:
Clean the equipment regularly with a soft cloth lightly moistened with alcohol
Lubricate moving parts periodically to ensure smooth operation
If the equipment is not used for an extended period, clean the moving surfaces and apply a protective anti-rust coating
Periodically inspect screws, nuts, pins, and other fasteners to prevent loosening
Safety Notes:
Do not place hands or other body parts near moving components or work-zone areas during operation
Operation should be performed by a single trained operator to avoid accidental injury
Disassembly should only be performed by qualified technicians
Specifications are provided for reference and may be adjusted to suit specific process requirements. Custom container sizes are available on request.
Note: Specifications listed above are typical and for reference only. Actual mixing and defoaming performance depend on the specific material formulation, viscosity, batch size, and process parameters. XN-PVMC-300mL is a bladeless centrifugal mixer ideal for contamination-sensitive samples and high-viscosity materials; for blade-based planetary mixing with multi-segment PLC speed control, see the Planetary Vacuum Mixer XN-PVM-500mL, and for simple single-shaft small-batch mixing see the Vacuum Mixer XN-VM-500mL. Slurries prepared with XN-PVMC-300mL can be coated downstream using the Automatic Film Coater XN-VC-300 or the Slot-Die Coating System XN-SDC. For materials, see our Cathode Materials and Anode Materials.
