Neware CE-4008Q 5V30A Battery Testing System, ENCE4008Q5V30A

SKU: ENCE4008Q5V30A

Neware CE-4008Q 5V30A Battery Testing System, ENCE4008Q5V30A — Neware CE-4008Q battery tester configured for 5 V / 30 A, with four current ranges, ±0.02% F.S. specified current accuracy, and 150 W/channel output.

Need help selecting a configuration? Request a competitive quote today!

Neware CE-4008Q 5V30A Battery Testing System, ENCE4008Q5V30A

Product Type: High-Current Battery Testing System
Brand: Neware
Part Number: ENCE4008Q5V30A

Product Introduction

The Neware CE-4008Q is a multi-range battery cycler designed for controlled testing at up to 5 V / 30 A. This configuration combines high-current output with programmable battery test steps for laboratory R&D and quality evaluation.

Key Features

• 5 V / 30 A configuration — rated output for this product
• Four current ranges — supports measurement across low- and high-current conditions
• ±0.02% F.S. current accuracy — specified full-scale current accuracy
• 150 W/channel — specified output power per channel
• Programmable cycling — supports CCC/CCD, CVC/CVD, CPC/CPD, CCCV, DCIR, and pulse simulation

Specification

Parameter	Specification
Part Number	ENCE4008Q5V30A
Power	AC110V or 220V±10%, single phase, 50/60Hz, 1800 W
Voltage Features	25 mV ~ 5V Minimal discharge voltage: 2.0 V for 2m cable Accuracy: ± 0.02% of F.S. Stability: 0.04% of F.S.
Current Features	There are four current ranges: Range 1: (1 A) Range 2: (6 A) Range 3: (12 A) Range 4: (30 A) Accuracy: ± 0.02% of F.S. Stability: 0.04% of F.S. Minimum Output Current: 0.5% of F.S. CV Cut-Off Current: 0.2% of F.S.
Output Power	150 W/Channel Accuracy: ± 0.04% of F.S. Stability: 0.08% of F.S.
Time	Current Response Time: ≤1.0 ms (10%-90% F.S.) Current Conversion Time: ≤10 ms (-90%-90% F.S.) Establishment Time: ≤10 ms (0-100% F.S.) Working Step Time: ≤(365*24) h/step Time format-00: 00: 00.000 (h、m、s、ms)
Cycle	Max. Cycles: 1-65535 Max. Steps: ≤255 Cycle Test: <10
Main Test Functions	Constant current charging/discharging (CCC/CCD) Constant voltage charging/discharging (CVC/CVD) Constant power charging/discharging (CPC/CPD) Constant current constant voltage charging/discharging (CCCVC/CCCVD) DCIR Pulse Simulation Test GITT
Clip Types	(1) Crocodile fixture (2) Polymer fixture
Integration Options (Optional)	Multiple testing units can be integrated with upper controller on a rack shelf.
Dimension	L483 * W438 * H130 mm
Weight	~15 kg
