Graphene-Coated Copper Foam XN-GCF
SKU: XN-GCF
Graphene-Coated Copper Foam XN-GCF is a CVD-grown graphene coating on a three-dimensional interconnected copper-foam substrate for research, electrochemical, sensing, thermal, and conductive-material applications.
Need a bulk order or custom specification? Request a competitive quote today!
Name: Graphene-Coated Copper Foam XN-GCF
Material Type: Graphene-Coated Copper Foam
Product Code: XN-GCF
Brand: Xnergy
Product Introduction:
XN-GCF is a three-dimensional graphene foam material prepared by chemical vapor deposition on a porous metal-foam scaffold. The graphene coating follows the interconnected foam network, producing a continuous three-dimensional porous architecture with a high accessible surface area. Copper-foam and nickel-foam substrate options are available.
Core Features:
- CVD-grown graphene coating
- Three-dimensional interconnected porous network
- Copper-foam or nickel-foam substrate options
- Continuous conductive scaffold architecture
- Multiple standard sample dimensions
- Custom dimensions available upon request
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Type | Graphene-coated three-dimensional metal foam |
| Product Code | XN-GCF |
| Brand | Xnergy |
| Coating Method | Chemical vapor deposition (CVD) |
| Substrate Options | Copper foam or nickel foam |
| Structure | Three-dimensional interconnected porous network |
| Available Substrate Sizes | 10 × 10 mm; 20 × 20 mm; 30 × 30 mm; 40 × 40 mm; 50 × 50 mm; 50 × 100 mm; 100 × 100 mm; 100 × 200 mm |
| Custom Dimensions | Available upon request |
Applications:
- Electrode and electrochemical-material research
- Supercapacitor and battery research
- Conductive three-dimensional scaffolds
- Catalyst-support research
- Sensors and field-emission research
- Thermal-management and composite-material research
Note: Dimensions refer to the listed substrate sample formats. Substrate metal and dimensions should be confirmed when requesting a quotation. Performance depends on the selected substrate, sample geometry, coating condition, and application setup. Explore the Copper Foam category or compare with the XN-CuF Copper Foam Sheet.
