LiFePO4 Cathode Sheet Single-Side Coating

LiFePO₄ Cathode Sheet (Single-Side Coating)

SKU: XN-LFP-ES

Free Shipping$210.00

LFP (LiFePO₄) Cathode Sheet on Aluminum Foil (Single-Sided) — LFP on 16 μm Al foil, 241 × 200 mm; coating 13.5 ± 0.2 mg/cm², compacted density 2.0 ± 0.1 g/cm³; AM content 95.4%; 5 sheets/pack.

Reference capacity 150 mAh/g at 0.1C (2.5–3.7 V).

Need a bulk order? Request a competitive quote today!

Name: LFP (LiFePO₄) Cathode Sheet on Aluminum Foil (Single-Sided Coating)

Material Type: LFP Lithium Iron Phosphate on 16 μm Aluminum Foil, Single-Sided Coating

Product Code: XN-LFP-ES

Product Introduction:

LiFePO₄ (LFP) is an iron-phosphate olivine cathode material known for excellent thermal stability, long cycle life, and inherent safety. This single-sided electrode sheet is coated on 16 μm aluminum foil with a coating areal density of 13.5 ± 0.2 mg/cm² and compacted density of 2.0 ± 0.1 g/cm³. Total electrode thickness is 70–90 μm. Reference specific capacity is 150 mAh/g at 0.1C (2.5–3.7 V). Sheet size is 241 mm × 200 mm. Supplied 5 sheets/pack.

Key Features:

LFP (LiFePO₄) — excellent thermal stability, long cycle life, and safety
Coating areal density 13.5 ± 0.2 mg/cm²
Compacted density 2.0 ± 0.1 g/cm³
Reference specific capacity 150 mAh/g at 0.1C (2.5–3.7 V)
Current collector: 16 μm aluminum foil, 4.22 mg/cm²
Active material weight ratio 95.4%
Total thickness 70–90 μm (single-sided, calendered)
Electrode size: 241 × 200 mm (coating area 241 × 175 mm, 12.5 mm uncoated edges on each side)
Packaging: 5 sheets/pack

Specifications:

Parameter Specification
Electrode Size 241 mm (L) × 200 mm (W)
Coating Area Size 241 mm (L) × 175 mm (W) (12.5 mm uncoated edge on each side)
Coating Type Single-sided coating (calendered)
Total Thickness (μm) 70–90
Current Collector Thickness (μm) 16
Coating Areal Density (mg/cm²) 13.5 ± 0.2
Current Collector Areal Density (mg/cm²) 4.22
Active Material Weight Ratio 95.4%
Compaction Density (g/cm³) 2.0 ± 0.1
Voltage Range 2.5–3.7 V
Reference Specific Capacity 150 mAh/g (0.1C)
Packaging 5 sheets/pack

Notes:

  1. The active material mass ratio should be confirmed from the product label; the above parameters are for reference only.
  2. After opening, please store the electrode sheet in a sealed condition. It can be kept in a glove box or in an oven at 60°C.

Storage & Handling:

Store sealed in a cool, dry, low-humidity environment. After opening, reseal immediately and store in a glove box or in a drying oven at 60°C. Handle by the edges to avoid contaminating the active coating.

Note: Specifications are for reference only. Actual electrochemical performance depends on counter/reference electrode selection, electrolyte, separator, cell assembly conditions, and cycling protocol. For anode electrode sheets, see the Anode Materials category. For electrolytes, see the Electrolytes category. For coin cell assembly components, see Coin Cells & Hardware.
