Monochromatic X-Ray Test Mold XN-GT07
SKU: XN-GT07
$268.00
Monochromatic X-Ray Test Mold (XN-GT07) — a standard fixture for synchrotron radiation, X-ray microscopic morphology research and material non-destructive testing. It is matched to ellipsoidal-focusing-mirror and zone-plate optical-path systems for absorption-contrast imaging, with tight machining tolerances for a stable monochromatic X-ray optical path. 20 mm sleeve diameter, 60 mm assembly height, Φ1–6 mm inner diameter, ≤500 MPa working pressure. Built from stainless steel, PEEK and Grade 4 steel.
Need a bulk order? Request a competitive quote today!
Monochromatic X-Ray Test Mold XN-GT07
Mold Type: Monochromatic X-Ray Test Mold
Product Code: XN-GT07
Brand: Xnergy
Product Introduction
The XN-GT07 is a monochromatic X-ray test mold used as a standard fixture for synchrotron radiation, X-ray microscopic morphology research, and material non-destructive testing. It is designed to work with ellipsoidal-focusing-mirror and zone-plate optical-path systems and is matched for absorption-contrast imaging.
Key Features
• Stable monochromatic X-ray optical path — machining tolerances are strictly controlled to ensure optical-path accuracy and stability.
– Optics compatibility — matched to ellipsoidal-focusing-mirror and zone-plate optical-path systems for absorption-contrast imaging.
– Standard research fixture for synchrotron radiation, X-ray microscopic morphology research and material non-destructive testing.
Selected Materials
Stainless steel · PEEK · Grade 4 steel
Specification
| Parameter | Specification |
|---|---|
| Model | XN-GT07 |
| Sleeve Diameter | 20 mm |
| Assembly Height | 60 mm |
| Inner Diameter | Φ1–6 mm |
| Material | Stainless Steel, PEEK, Grade 4 Steel |
| Maximum Working Pressure | ≤500 MPa |
Application Areas
• New Energy
– Lithium Battery Research
– Research Projects
– Electrochemistry
– Mold Customization
– Solid-State Battery
Customization
Flexible customization — the structure and specifications can be optimized to specific experimental needs, with multiple Φ1–6 mm inner-diameter options and customizable mold material. The electrode post is supplied at a default diameter of Φ2 mm; other sizes are available on request.
Note: For in-situ Raman testing, see the XN-GT06; for low-profile microscopic observation, the XN-GT08; and for end-face Raman testing, the XN-GT16. Browse the full range under Battery Molds.
